Attacking OpenStack
Attacking OpenStack, an open-source cloud computing platform, involves exploiting vulnerabilities in its components and configuration to gain unauthorized access or disrupt services. One common attack vector is through the OpenStack Dashboard (Horizon), which can be susceptible to cross-site scripting (XSS) and cross-site request forgery (CSRF) attacks if not properly secured. Attackers can also target the API endpoints, which are often exposed to the internet. By exploiting insecure API calls or leveraging weak authentication mechanisms, attackers can manipulate cloud resources, potentially leading to data breaches or service interruptions. Furthermore, insecure configurations, such as using default passwords or failing to apply security patches, provide additional opportunities for exploitation.
Another critical aspect of attacking OpenStack is leveraging vulnerabilities within its network and storage components. OpenStack's Neutron, responsible for networking, can be targeted through attacks on the underlying network infrastructure, such as VLAN hopping or manipulating network policies to intercept or reroute traffic. Similarly, the Cinder and Swift services, which handle block and object storage respectively, can be exploited if they are misconfigured, allowing attackers to access or corrupt stored data. Privilege escalation attacks are also a significant threat, where attackers can exploit vulnerabilities in the underlying hypervisor or the Keystone identity service to gain higher-level access, thereby compromising the entire cloud environment. Ensuring comprehensive security measures, regular updates, and stringent access controls are crucial to
Apply Restrictive File Permissions
To ensure the security of files containing sensitive information, such as configuration files with passwords, it is crucial to apply restrictive file permissions. This prevents unauthorized access and potential exploitation through information disclosure or code execution. Files should be created with permissions that limit access to only the owning user or service and group, avoiding any world/other access.
Incorrect Example
Consider a configuration file for a service named "secureserv" stored in secureserv.conf
. If the file permissions are set as follows:
ls -l secureserv.conf
-rw-rw-rw- 1 secureserv secureserv 6710 Feb 17 22:00 secureserv.conf
The file permissions are set to 666
, allowing read and write access to everyone on the system. This is insecure because it exposes the sensitive information contained within the configuration file to all users.
Parameterize Database Queries
Often we write code that interacts with a database using parameters provided by the application’s users. These parameters include credentials, resource identifiers, and other user-supplied data.
Care must be taken when dynamically creating database queries to prevent them from being subverted by user-supplied malicious input. This is generally referred to as SQL injection (SQLi). SQL injection works because the user input changes the logic of the SQL query, resulting in behavior that is not intended by the application developer.
The results of a successful SQL injection attack can include disclosure of sensitive information such as user passwords, modification or deletion of data, and gaining execution privileges, which would allow an attacker to run arbitrary commands on the database server.
SQL injection can typically be mitigated by using some combination of prepared statements, stored procedures, and escaping of user-supplied input. Most secure web applications will use all three, and we have described their use below.
Consequences
If sensitive information options are logged without being marked as secret, that sensitive information would be exposed whenever the logger debug flag is activated.
Example Log Entries
2015-02-18 20:46:48.928 25351 DEBUG nova.openstack.common.service [-] Full set of CONF: _wait_for_exit_or_signal /usr/lib/python2.7/dist-packages/nova/openstack/common/service.py:166
2015-02-18 20:46:48.937 25351 DEBUG nova.openstack.common.service [-] Configuration options gathered from: log_opt_values /usr/lib/python2.7/dist-packages/oslo/config/cfg.py:1982
2015-02-18 20:46:51.482 25351 DEBUG nova.openstack.common.service [-] host.ip = 127.0.0.1 log_opt_values /usr/lib/python2.7/dist-packages/oslo/config/cfg.py:2002
2015-02-18 20:46:51.491 25351 DEBUG nova.openstack.common.service [-] host.port = 443 log_opt_values /usr/lib/python2.7/dist-packages/oslo/config/cfg.py:2002
2015-02-18 20:46:51.502 25351 DEBUG nova.openstack.common.service [-] host.username = root log_opt_values /usr/lib/python2.7/dist-packages/oslo/config/cfg.py:2002
2015-02-18 20:46:51.486 25351 DEBUG nova.openstack.common.service [-] host.password = secrets! log_opt_values /usr/lib/python2.7/dist-packages/oslo/config/cfg.py:2002
Use Secure Channels for Transmitting Data
Data in transit over networks should be protected wherever possible. Although some data may not appear to have strong confidentiality or integrity requirements, it is best practice to secure it.
When building any application that communicates over a network, we have to assume that we do not control the network that the data travels over. We should consider that the network may have hostile actors who will attempt to view or change the data that we are transmitting.
Clear Example
OpenStack API calls often contain credentials or tokens that are very sensitive. If they are sent in plaintext, they may be modified or stolen.
It is very important that API calls are protected from malicious third parties viewing them or tampering with their content - even for communications between services on an internal network.
Less Obvious Example
Consider a server process that reports the current number of stars in the sky and sends the data over the network to clients using a simple webpage. There is no strong confidentiality requirement for this; the data is not secret. However, integrity is important. An attacker on the network could alter the communications going from the server to clients and inject malicious traffic such as browser exploits into the HTTP stream, thus compromising vulnerable clients.
Incorrect
cfg.StrOpt('protocol',
default='http',
help='Default protocol to use when connecting to glance.')
Correct
cfg.StrOpt('protocol',
default='https',
help='Default protocol to use when connecting to glance.')
Escape User Input to Prevent XSS Attacks
These days, almost every service we create has some form of web interface, be it for administration, monitoring, or for the core functionality of the service. These interfaces are becoming ever more complex and dynamic, and increasingly interactive. There is a risk, however, when increasing the interactivity of these web services, that we inadvertently allow a user to supply data which can corrupt or disrupt the normal running of that service.
Cross-Site Scripting (XSS) is a class of vulnerability whereby an attacker is able to present active web content to a web service, which is subsequently echoed back to a user and executed by the browser. This content can be as seemingly benign as an embarrassing image or text, or as malign as browser-based exploits intended to steal and utilize the user’s web session, or even compromise the user’s web browser and take control of their client system.
There are three main classes of XSS issues: Persistent, Reflected, and DOM-Based. Persistent XSS issues are those where user input is stored by the server, either in a database or on the filesystem. This data is subsequently retrieved and rendered into the web page as if it were legitimate content. Reflected XSS issues are where user input is presented to the server and then immediately reflected back to the client. This data is never stored by the server. DOM-Based XSS issues occur entirely within the browser.
Incorrect
In the below example, user-supplied data from the query string is written directly into the HTML document and is presented to the user.
def index(request):
name = request.GET.get('name')
return f"<html><body>Hello {name}!</body></html>"
Correct
In the below example, the same user-supplied data is escaped before being written into the document, thus preventing the user from adding HTML elements to the document.
from html import escape
def index(request):
name = request.GET.get('name')
safe_name = escape(name)
return f"<html><body>Hello {safe_name}!</body></html>"
In addition to the use of escaping, frameworks and templating engines can also be useful in preventing XSS attacks.
